T300-1 OUTRIGGERS SET TO:2500 psi
T500-1 OUTRIGGERS SET TO:2500 psi
T780 OUTRIGGERS SET TO: 2500 psi
OUTRIGGER RELIEF ADJUSTMENT
With the test gauge still attached to the test port, remove the hex cap, insert an allen
wrench. adjust to the proper setting while holding the outrigger in the retract position. Turn
in to increase pressure, out to decrease. After completing adjustment, replace cap on the
relief valve.
483P/N 12261-683 REVISED: January 2015
