Changing the engine oil
Fig. 6-8 Changing the engine oil
Run the engine warm (engine oil temperature approx. 80°C).
Park the machine in horizontal position.
Shut down the engine.
Remove the cap from the bottom rear-end.
Place suitable oil collecting vessels under the engine block.
Screw the oil drain hose onto the oil change valve (1).
Drain off all engine oil.
Remove the oil drain hose and turn the protective cab back on the valve (1).
Close the service opening with the cover.
Replace the engine oil filter (2). See chapter "Changing the engine oil filter",
page 69.
Fill in engine oil through the filler opening (3) until the oil level reaches the
"MAX"-mark on the dipstick (4).
Start the engine and run at low idle speed for approx. 2 min.
Shut down the engine.
Check the oil level and top up oil if required.
Danger of burning
Danger of scalding by hot oil.
Z Be careful when draining hot
oil.
Z Wear suitable protective
clothing and safety goggles.
