TL260
Maintenance
80 / 187
6
06_Maintenance_en.fm - V 0.1 - 14.4.11
11
Cleaning the main cartridge
Fig. 6-18 Changing the air filter cartridges
The main cartridge can be cleaned up to five times if necessary. It must be
replaced once it reaches its maximum service life of two years, at the latest. The
number of times it is cleaned must be marked.
For cleaning (1), attach a pipe the end of which is bent at 90° to a
compressed-air pistol. It must be sufficiently long to reach the floor of the
cartridge. Blow out the main cartridge from the inside to the outside with dry
compressed air (max. 5 bar) by moving the pipe up and down in the cartridge
and continue until no more dust escapes.
Check the clean main cartridge for damage to the paper bellows and rubber
seals (2). Tears and perforations in the paper bellows can be determined
using a torch.
Property damage
Machine damage due to
damaged main cartridge.
Z Never wash or brush out the
main cartridge.
Z When blowing out, ensure that
dust does not land on the
inside of the main cartridge.
Z Never continue to use
damaged main cartridges. If in
doubt, use a new one.
