TL260
Maintenance
06_Maintenance_en.fm - V 0.1 - 14.4.11
97 / 187
6
11
Change the crawler gear oil
Fig. 6-34 Changing the crawler gear oil
Park the machine in horizontal position.
Clean the area around the checking-filler plug (1) and drain plug (2).
Open the checking-filler plug (1).
Unscrew the drain plug (2) and drain oil.
Carefully seal the drain plug (2).
Pour in oil using the checking-filler plug (1) until it reaches the bottom edge.
Carefully seal the checking-filling plug (1).
Damage to property
Machine damage from incorrect
oil.
Z Use automatic transmission oil!
See chapter 6.4.2
"Consumables", page 52.
4560_6036
1
2
