10
Fast displacement
When measuring bores or grooves, this function
can be enabled to shift the probe faster from the
upper to the lower point and the other way round.
Bore measurement
A second short rotation of the power control in the
same direction permits bore measurement with
detection of the culmination point.
–Turn the power control clockwise to start probing
the upper point.
–Turn the rotary power control counterclockwise,
to start probing the lower point first.
Stop
A second or third short rotation in reverse
direction causes the probe insert to stop.
– Selected measuring function is then quit.
