6 Probe contact procedure is completed.
Probe insert retracts automatically.
Measured values are normally displayed.
7 Main display shows the difference between both
probe contacts for a while. Numbered value is
incremented providing dip switch 6 is set on ON
8 Main display shows the difference between both
probe contacts permanently. Displayed values are
not retained in the memory once the height gauge
has been switched off.
1 Probe contact procedure.
Press both relevant keys or use the rotary power
control for correct positioning of the probe insert
into the bore.
Enabling keys/gauge Displaying Explanation
4.11
Measuring
bores
