1 GENERAL FEATURES
Cover plate 1
Transmission band 2
13
Setting screw for air-cushion
9 Handle
10 1D control panel
11 Switch for electric pump
12 Rotary power control
8 Three-point cast-iron base
Housing
3
Mounting pin 4
Probe fixing arm 5
Probe 6
Guiding face with resting points 7
Fig. 1
