TESA Micro-Hite Plus M User Manual

M
3
1 General features page 04
2 Installation page 06
2.1 Unpacking and setting up page 06
2.2 Getting started page 06
3 Key components page 08
3.1 Height gauge base page 08
3.2 Air-bearing base page 08
3.3 Vertical column, measuring head, head displacement page 08
3.4 Rotary power control page 08
3.5 Power supply page 11
3.6 Measuring system page 11
3.7 Automatic value correction page 11
3.8 Control panels page 12
4 Measuring page 12
4.1 General page 12
4.2 1D Control panel with function keys page 14
4.3 Power Panel plus M with function keys page 16
4.4 Probing procedure at the contact point page 17
4.5 Establishing the probe constant page 20
(for length measurements with inversion of the probing direction)
4.6 Programming retraction travel page 22
4.7 Capturing a reference value page 23
4.8 PRESET mode page 25
4.9 Measuring grooves page 27
4.10 Measuring ribs page 29
4.11 Measuring bores page 30
4.12 Measuring shafts page 32
4.13 Calculating distances page 34
4.14 Measuring centre distances of threads page 37
4.15 Measuring flatness or parallelism on flat surfaces page 38
4.16 Measuring deviations from perpendicularity using a dial-test indicator page 40
4.17 Measuring deviations form perpendicularity or straightness using page 40
a TESA IG-13 digital probe
5 Maintenance page 42
5.1 General cleaning page 42
5.2 Recharging batteries page 42
5.3 Changing worn-out batteries page 42
6 Delivery programme page 43
6.1 TESA Micro-hite plus M height gauges page 43
6.2 Control panels page 44
6.3 Optional accessories page 45
7 Technical data page 50
7.1 RS 232 digital interface page 51
7.2 Monodirectional data transmission page 51
7.3 Bidirectional data transmission page 51
8 Warranty page 51
9 Declaration of conformity page 52
TABLE OF CONTENTS

TESA Micro-Hite Plus M Specifications

General

Brand	TESA
Model	Micro-Hite Plus M
Category	Measuring Instruments
Language	English
