TESA Micro-Hite Plus M - Measuring Flatness and Parallelism

38
M
Enabling keys/gauge Displaying Explanation
max
0
3
max
0
4
8
0
2
Select probing direction by pressing both keys
and .
4
1
1 Use relevant keys or the rotary power control for
correct positioning of the probe insert.
4.15
Measuring flatness
or parallelism on
flat surfaces
The mode enabling both MAX/MIN
points to be detected can be accessed
from any position by simply activating
function key .
8
To leave this menu and return to the reference mode
previously quitted, press the function key .
8
