Dip switch settings
SW1 Resolution selection (0.1 µm / 1 µm). Probe speed switches over from 7,5 to 15 mm/s
before starting measuring.
SW2 EXT.P selection (to enable PRINT function or repeat last measuring function).
SW3 Stabilisation time selection (1 s or infinite). In the latter case, press ENTER for value
capture.
SW4 BEEP sound selection (ON or OFF).
SW5 Automatic or manual PRINT selection. Either function is selected after each measuring
operation or in case display has switched over.
SW6 OFF selection: only the last two displayed values will be retained in the memory since
numbering is omitted.
ON selection: automatic numbering of up to 99 values.
SW7 OFF selection: height gauge switches itself off after 20 minutes if no function key is
activated.
ON selection: height gauge is turned off by pressing ON/OFF key.
SW8 to SW10 DATA mode selection. If these switches are set on OFF, rough value is sent to the RS port.
Other settings enable language selection for headings.
SW SW1 SW2 SW3 SW4 SW5 SW6 SW7
OFF 0.1 µm/0.00001¨ Ext. P = t = Print Auto
7,5 mm/s Print 1 s manual OFF OFF
ON 1 µm/0.0001¨ Ext P = t = Print 1, 2, n ON/
15 mm/s Measure 00 auto OFF
Data French German English Spanish Italian Portuguese Swedish
SW8 OFF ON OFF ON OFF ON OFF ON
SW9 OFF OFF ON ON OFF OFF ON ON
SW10 OFF OFF OFF OFF ON ON ON ON
