MICRO-HITE PLUS M HEIGHT GAUGES,
1D CONTROL PANEL, POWER PANEL PLUS M 350 600 900
Measuring span 365 mm 615 mm 920 mm
Application range
with standard insert holder 00760143 520 mm 770 mm 1075 mm
Application range
with standard insert holder 00760057 575 mm 825 mm 1130 mm
Application range
with insert holder S07001622 745 mm 995 mm 1300 mm
Max. perm. error (2+ 1.5 L) µm – (L in m)
Repeatability on flat surfaces: 2 s = <0.5 µm – Within bores: 2 s = <1 µm
Max. deviation from perpendicularity Mechanical perpendicularity (frontal)
< 6 µm < 8 µm < 12 µm
These values are valid with height gauge linked to a digital handtool
< 5 µm < 6 µm < 10 µm
Resolution 1D control panel: 0.0001/0.001 mm – 00001/.0001in
Power Panel plus M: 0.0001/0.001/0.01 mm – .00001/.0001/.001/.01/.1in
Displacement speed 600 mm/s (hand operated) – 30 mm/s (motorised fast motion)
Probing speed 7,5 / 15 mm/s 7,5 / 15 mm/s 7,5 / 15 mm/s
Measuring force 1N 1N 1N
Autonomy ~12 h ~12 h ~12 h
Masse ~33 kg ~38 kg ~45 kg
Air-bearing base yes (3-point bearing) yes (3-point bearing yes (3-point bearing)
Batteries Battery pack 00760141
Data output 1D control panel: RS-232
Power Panel plus M: RS-232 and Centronics
Degree of protection IP 40 IP 40 IP 40
Carriage lock no no no
Storage temperature range -10°÷60° -10°÷60° -10°÷60°
Operating temperature range 5°÷40° 5°÷40° 5°÷40°
Two-dimensional measurement capability 1D power panel: no
Power Panel plus M: yes
Printer For direct printing of inspection reports in A4 format.
Suitable for use with Power Panel plus M.
Built-in printer For direct printing with header.
Suitable for use with Power Panel plus M 00760220.
