TESA Micro-Hite Plus M User Manual

M
7
St 1
Probe
datum point
Cancel
reference
Probe constant
capture
St 2
Probe
datum point
Switch the instrument on
Using the
1D control panel
(N° 00760216)
Using either of both
Power Panels Plus M
(N° 00760220
or 00760221)
Probe insert moves automatically, travels past the reference mark of the precision glass scale for initialisation,
then places itself into position at the centre of the master piece.
ON
OFF
Cancel
reference
Measure Measure
St 1
Probe
datum point
Cancel
reference A or B
Probe constant
capture
St 2
Probe
datum point
Switch the instrument on
Access mode
for perpendicularity
measurement?
Probe insert moves automatically, travels past the reference mark of the precision glass scale for initialisation,
then places itself into position at the centre of the master piece.
ON
OFF
Cancel both
references A and B
Cancel
reference A or B
Measure Measure
Cancel both
references A and B
yes
no
no
no
Is TESA IG-13
connected?
