TESTO Saveris - Installing Saveris software

7 Using the product
51
Range limits tab
Name Explanation
Display range limits Specification as to whether the limit
values should be shown in the
diagram.
Add limit labels
Specification as to whether the limit
values should be labelled
(Upper/Lower limit value: name of
curve).
Area fill
Specification as to whether the areas
outside the limit values should be
marked by means of an area fill.
Selection list for area fill Selection of the fill.
Line fill Specification as to whether the limit
values should be shown by horizontal
lines.
Selection lists for line fill
Selection lists for line type and line
thickness.
Overshot
Colour selection for filling the area
above the upper limit value.
Undershot Colour selection for filling the area
below the lower limit value.
