7 Using the product
53
Name Explanation
Specification that the axes are divided
in a linear manner.
Specification that the axes are divided
logarithmically, meaning the division
increments represent powers of ten.
Applies the settings until other data
are called up. The dialogue is closed.
Closes the dialogue without applying
any changes at all.
Specification as to whether the
program should perform scaling of the
Range of values from...to
Manual input of the value range when
Automatic scale is disabled.
Specification that the program should
perform the division of the axis.
Specification that the division of the
axis should be performed manually.
Grid [<], [>] (when automatic division
is enabled)
By clicking on [<] or [>], make the axis
division larger or smaller.
Interval (when manual division is
Manual entry of the grid.
Settings for the time axis
With the right mouse button, click on the time axis in the diagram.
The Adjust time axis dialogue is
displayed.
