6.10.2 Main Features of Flash Module
• Support for multiple flash banks for program and/or data storage
• Simultaneous read access on a bank while performing program or erase operation on any other bank
• Integrated state machines to automate flash erase and program operations
• Pipelined mode operation to improve instruction access interface bandwidth
• Support for Single Error Correction Double Error Detection (SECDED) block inside Cortex-R4F CPU
– Error address is captured for host system debugging
• Support for a rich set of diagnostic features
6.10.3 ECC Protection for Flash Accesses
All accesses to the program flash memory are protected by SECDED logic embedded inside the CPU.
The flash module provides 8 bits of ECC code for 64 bits of instructions or data fetched from the flash
memory. The CPU calculates the expected ECC code based on the 64 bits received and compares it with
the ECC code returned by the flash module. A single-bit error is corrected and flagged by the CPU, while
a multibit error is only flagged. The CPU signals an ECC error through its Event bus. This signaling
mechanism is not enabled by default and must be enabled by setting the "X" bit of the Performance
Monitor Control Register, c9.
MRC p15,#0,r1,c9,c12,#0 ;Enabling Event monitor states
ORR r1, r1, #0x00000010
MCR p15,#0,r1,c9,c12,#0 ;Set 4th bit (‘X’) of PMNC register
MRC p15,#0,r1,c9,c12,#0
The application must also explicitly enable the ECC checking of the CPU for accesses on the CPU ATCM
and BTCM interfaces. These are connected to the program flash and data RAM, respectively. ECC
checking for these interfaces can be done by setting the B1TCMPCEN, B0TCMPCEN, and ATCMPCEN
bits of the System Control Coprocessor Auxiliary Control Register, c1.
MRC p15, #0, r1, c1, c0, #1
ORR r1, r1, #0x0e000000 ;Enable ECC checking for ATCM and BTCMs
DMB
MCR p15, #0, r1, c1, c0, #1
6.10.4 Flash Access Speeds
For information on flash memory access speeds and the relevant wait states required, see
Section 5.8.1.2.
