TMS570LS0714
www.ti.com SPNS226E –JUNE 2013–REVISED NOVEMBER 2016
Submit Documentation Feedback
Product Folder Links: TMS570LS0714
SpecificationsCopyright © 2013–2016, Texas Instruments Incorporated
(1) All voltages are with respect to V
SS
, except V
CCAD
, which is with respect to V
SSAD
(2) Reliability data is based upon a temperature profile that is equivalent to 100,000 power-on hours at 105°C junction temperature.
5.4 Recommended Operating Conditions
(1)
over operating free-air temperature range (unless otherwise noted)
TEST CONDITIONS MIN NOM MAX UNIT
V
CC
Digital logic supply voltage (Core) 1.14 1.2 1.32 V
V
CCIO
Digital logic supply voltage (I/O) 3 3.3 3.6 V
V
CCAD
MibADC supply voltage 3 5.25 V
V
CCP
Flash pump supply voltage 3 3.3 3.6 V
V
SS
Digital logic supply ground 0 V
V
SSAD
MibADC supply ground –0.1 0.1 V
V
ADREFHI
Analog-to-digital high-voltage reference source V
SSAD
V
CCAD
V
V
ADREFLO
Analog-to-digital low-voltage reference source V
SSAD
V
CCAD
V
V
SLEW
Maximum positive slew rate for V
CCIO
, V
CCAD
and
V
CPP
supplies
1 V/μs
V
hys
Input hysteresis All inputs 180 mV
V
IL
Low-level input voltage All inputs –0.3 0.8 V
V
IH
High-level input voltage All inputs 2 V
CCIO
+ 0.3 V
T
A
Operating free-air temperature –40 125 °C
T
J
Operating junction temperature
(2)
–40 150 °C
