3 Device Comparison
Table 3-1 lists the features of the TMS570LS0714 devices.
Table 3-1. TMS570LS0714 Device Comparison
FEATURES TMS570LS DEVICES
Generic Part Number 3137ZWT
(1)
1227ZWT
(1)
0914PGE
(1)
0714PGE 0714PZ 0432PZ
Package 337 BGA 337 BGA 144 QFP 144 QFP 100 QFP 100 QFP
CPU ARM Cortex-R4F ARM Cortex-R4F ARM Cortex-R4F ARM Cortex-R4F ARM Cortex-R4F ARM Cortex-R4
Frequency (MHz) 180 180 160 160 100 80
Flash (KB) 3072 1280 1024 768 768 384
RAM (KB) 256 192 128 128 128 32
Data Flash [EEPROM]
(KB)
64 64 64 64 64 16
EMAC 10/100 10/100 – – – –
FlexRay 2-ch 2-ch – – – –
CAN 3 3 3 3 2 2
MibADC
12-bit (Ch)
2 x (24ch) 2 x (24ch) 2 x (24ch) 2 x (24ch) 2 x (16ch) 1 x (16ch)
N2HET (Ch) 2 (44) 2 (44) 2 (40) 2 (40) 2 (21) 1 (19)
ePWM Channels – 14 14 14 8 –
eCAP Channels – 6 6 6 4 0
eQEP Channels – 2 2 2 1 2
MibSPI (CS) 3 (6 + 6 + 4) 3 (6 + 6 + 4) 3 (5 + 6 + 1) 3 (5 + 6 + 4) 2 (5 + 1) 1 (4)
SPI (CS) 2 (2 + 1) 2 (2 + 1) 1 (1) 1 (1) 1 (1) 2
SCI (LIN) 2 (1 with LIN) 2 (1 with LIN) 2 (1 with LIN) 2 (1 with LIN) 1 (with LIN) 1 (with LIN)
I2C 1 1 1 1 – –
GPIO (INT)
120 (with 16 interrupt
capable)
101 (with 16 interrupt
capable)
64 (with 10 interrupt
capable)
64 (with 10 interrupt
capable)
45 (with 9 interrupt
capable)
45 (with 8 interrupt
capable)
EMIF 16-bit data 16-bit data – – – –
ETM (Trace) 32-bit – – – – –
RTP/DMM YES – – – – –
Operating
Temperature
-40ºC to 125ºC -40ºC to 125ºC -40ºC to 125ºC -40ºC to 125ºC -40ºC to 125ºC -40ºC to 125ºC
Core Supply (V) 1.14 V – 1.32 V 1.14 V – 1.32 V 1.14 V – 1.32 V 1.14 V – 1.32 V 1.14 V – 1.32 V 1.14 V – 1.32 V
I/O Supply (V) 3.0 V – 3.6 V 3.0 V – 3.6 V 3.0 V – 3.6 V 3.0 V – 3.6 V 3.0 V – 3.6 V 3.0 V – 3.6 V
3.1 Related Products
For information about other devices in this family of products or related products, see the following links.
Products for TMS570 16-Bit and 32-Bit MCUs
An expansive portfolio of software and pin-compatible high-performance ARM
®
Cortex
®
-R-based MCU
products from 80 MHz up to 300 MHz with on-chip features that prove a high level of diagnostic coverage,
as well as provide scalability to address a wide range of applications.
Companion Products for TMS570LS0714
Review products that are frequently purchased or used with this product.
