66
TMS570LS0714
SPNS226E –JUNE 2013–REVISED NOVEMBER 2016
www.ti.com
Submit Documentation Feedback
Product Folder Links: TMS570LS0714
System Information and Electrical Specifications Copyright © 2013–2016, Texas Instruments Incorporated
(1) Flash bank0 is a 144-bit-wide bank with ECC support.
(2) Flash bank7 is a 72-bit-wide bank with ECC support.
(3) The flash bank7 can be programmed while executing code from flash bank0.
(4) Code execution is not allowed from flash bank7.
6.10 Flash Memory
6.10.1 Flash Memory Configuration
Flash Bank: A separate block of logic consisting of 1 to 16 sectors. Each flash bank normally has a
customer-OTP and a TI-OTP area. These flash sectors share input/output buffers, data paths, sense
amplifiers, and control logic.
Flash Sector: A contiguous region of flash memory which must be erased simultaneously due to physical
construction constraints.
Flash Pump: A charge pump which generates all the voltages required for reading, programming, or
erasing the flash banks.
Flash Module: Interface circuitry required between the host CPU and the flash banks and pump module.
Table 6-22. Flash Memory Banks and Sectors
MEMORY ARRAYS (OR BANKS)
SECTOR
NO.
SEGMENT LOW ADDRESS HIGH ADDRESS
BANK0 (768KB)
(1)
0 16KB 0x0000_0000 0x0000_3FFF
1 16KB 0x0000_4000 0x0000_7FFF
2 16KB 0x0000_8000 0x0000_BFFF
3 16KB 0x0000_C000 0x0000_FFFF
4 16KB 0x0001_0000 0x0001_3FFF
5 16KB 0x0001_4000 0x0001_7FFF
6 32KB 0x0001_8000 0x0001_FFFF
7 128KB 0x0002_0000 0x0003_FFFF
8 128KB 0x0004_0000 0x0005_FFFF
9 128KB 0x0006_0000 0x0007_FFFF
10 128KB 0x0008_0000 0x0009_FFFF
11 128KB 0x000A_0000 0x000B_FFFF
BANK7 (64KB) for EEPROM emulation
(2)(3)(4)
0 4KB 0xF020_0000 0xF020_0FFF
1 4KB 0xF020_1000 0xF020_1FFF
2 4KB 0xF020_2000 0xF020_2FFF
3 4KB 0xF020_3000 0xF020_3FFF
4 4KB 0xF020_4000 0xF020_4FFF
5 4KB 0xF020_5000 0xF020_5FFF
6 4KB 0xF020_6000 0xF020_6FFF
7 4KB 0xF020_7000 0xF020_7FFF
8 4KB 0xF020_8000 0xF020_8FFF
9 4KB 0xF020_9000 0xF020_9FFF
10 4KB 0xF020_A000 0xF020_AFFF
11 4KB 0xF020_B000 0xF020_BFFF
12 4KB 0xF020_C000 0xF020_CFFF
13 4KB 0xF020_D000 0xF020_DFFF
14 4KB 0xF020_E000 0xF020_EFFF
15 4KB 0xF020_F000 0xF020_FFFF
