TMS570LS0714
www.ti.com SPNS226E –JUNE 2013–REVISED NOVEMBER 2016
Submit Documentation Feedback
Product Folder Links: TMS570LS0714
Terminal Configuration and FunctionsCopyright © 2013–2016, Texas Instruments Incorporated
4.2.2.17 Ground Reference for All Supplies Except VCCAD
Table 4-36. PZ Ground Reference for All Supplies Except VCCAD
Terminal Signal
Type
Reset Pull
State
Pull Type Description
Signal Name 100
PZ
VSS 7 Ground – – Device Ground Reference. This is a single
ground reference for all supplies except for the
ADC Supply.
VSS 17
VSS 20
VSS 29
VSS 33
VSS 59
VSS 72
VSS 86
VSS 87
VSS 100
4.3 Pin Multiplexing
This microcontroller has several interfaces and uses extensive multiplexing to bring out the functions as
required by the target application. The multiplexing is mostly on the output signals. A few inputs are also
multiplexed to allow the same input signal to be driven in from a selected terminal.
4.3.1 Output Multiplexing
Table 4-37 and Table 4-38 show the pin multiplexing control x register (PINMMRx) and the associated bit
fields that control each pin mux function.
