Thermo King SPECTRUM SL User Manual

1 Introduction
ABOUT THIS MANUAL
The information in this manual is provided to assist owners,
operators and service people in the proper upkeep and
maintenance of Thermo King units. Each unit family includes
many specific models. When maintenance information differs
between models within a unit family, this manual uses specific
unit model nomenclature. When maintenance information for
specific models within a unit family is the same, this manual
uses unit family nomenclature.
UNITS COVERED
The maintenance information in this manual covers models:
Unit Family Specific Unit Models
SL = SL-100, SL-200, SL-300, SL-400, SL TCI
SLe = SL-100e, SL-200e, SL-400e, Spectrum SL
SLX = SLX-100, SLX-200, SLX-300, SLX-400
SLXe = SLXe-100, SLXe-200, SLXe-300,
SLXe-400, SLXe Whisper, SLXe-300
Whisper Pro
SLXi = SLXi-100, SLXi-200, SLXi-300,
SLXi-400, SLXi-300 Whisper Pro
Spectrum = Multi-temperature System: Spectrum SL,
SLX/SLXe/SLXi SPECTRUM,
SLXe/SLXi Spectrum Whisper Pro
SR = Units with a µP-IV controller
TCI = Multi-temperature System: SL TCI, host
unit with single evaporator
µP-IV = µP-IV, µP-IV+ and Multi-Temp µP-IV
controller
SL =
SL-100, SL-200, SL-300, SL-400, SL TCI
Single Temperature Systems (system number)
SL-100 30 (049134)
SL-100 50 (049133)
SL-200 30 (049124)
SL-200 50 (049123)
SL-300 30 (049122)
SL-300 50 (049121)
SL-400 30 (049136)
SL-400 50 (049135)
Multi-temperature Systems (system number)
SL-300 30 TCI-2 (049117)
SL-300 30 HC TCI-2 (049117 w/049122)
SL-300 30 TCI-3 (049118)
SL-300 30 HC TCI-3 (049118 w/049122)
SL-300 50 TCI-2 (049115)
SL-300 50 HC TCI-2 (049115 w/049121)
SL-300 50 TCI-3 (049106)
SL-300 50 HC TCI-3 (049106 w/049121)
TLE-2 (918060)
TLE-3 (918061)
SLe = SL-100e, SL-200e, SL-400e, Spectrum SL
Single Temperature Systems (system number)
SL-100e 30 (049172)
SL-100e 50 (049173)
SL-200e 30 (049174)
SL-200e 50 (049175)
SL-400e 30 (049176)
SL-400e 50 (049177)
SL-400e SR-2 30 (049198)
SL-400e SR-2 50 (049199)
Multi-temperature Systems (system number)
Spectrum SL 30-2 (049178)
Spectrum SL 30-3 (049180)
Spectrum SL 50-2 (049179)
Spectrum SL 50-3 (049181)
Spectrum Remote Evaporator S-2 (919170)
Spectrum Remote Evaporator S-3 (919171)
SLX = SLX-100, SLX-200, SLX-300, SLX-400
Single Temperature Systems (system number)
SLX-100 30 (900707)
SLX-100 50 (900706)
SLX-200 30, MTV (900703)
SLX-200 30, ETV(900703)-change to SLX-300(04-09)
SLX-200 50, MTV (900702)
SLX-200 50, ETV(900702)-change to SLX-300(04-09)
SLX Whisper 30, (901491)
SLX Whisper 50, (901489)
SLX-400 30, ETV(900705)
SLX-400 50, ETV(900704)
SLX-400 50, ETV/200 Volt (900704)
Multi-temperature Systems (system number)
SLX SPECTRUM 30-2 (901033)
SLX SPECTRUM 30-3 (901035)
SLX SPECTRUM 50-2 (901034)
SLX SPECTRUM 50-3 (901036)
Spectrum Remote Evaporator S-2 (900279)
Spectrum Remote Evaporator S-3 (900280)
SLXe = SLXe-100, SLXe-200, SLXe-300, SLXe-400,
SLXe Whisper
Single Temperature Systems (system number)
SLXe-100 30 (902289, 903098)
SLXe-100 50 (902288, 903097)
SLXe-200 30, MTV (902296, 903101)
SLXe-200 50, MTV (902295, 903099)
SLXe-300 30, ETV(902298, 903103)
SLXe-300 50, ETV(902297, 903102)
SLXe-400 30, ETV(902300, 903111)
SLXe-400 50 200-400V, ETV(902299, 903109)
SLXe-400 50 230V, ETV(901853, 903124)
SLXe Whisper 30, (902447, 903126)
SLXe Whisper 50, (902445, 903125)
