Engine Maintenance 9-3
ENGINE AIR CLEANER
Dry Type
A dry element air cleaner filters all of the air entering the engine. Excessive restriction of the air intake system affects horsepower,
fuel consumption and engine life.
1. Air Heater
2. Air Restriction Indicator
3. Intake Manifold
4. Restrictor in Breather Hose
5. Crankcase Breather
Crankcase Breather System – TK 486V Engine
1. Breather Hose
2. Insulation
3. Breather Cover
4. O-Ring
5. Baffle Breather
6. Baffle Plate
7. Intake Manifold
8. Restrictor Location
7
6
5
2
3
4
1
8
