Streaming Data Configuration The Streaming Data Configuration menu is used to allow for configuration
of the 18 streaming data output items, streaming interval, current data
format, and current time. The Choose Stream Data submenu displays a list
of the analog signal group choices to choose from. Choices are
Concentrations, Other Measurements, and Analog Inputs (if the I/O
expansion board option is installed).
Note Add Labels and Prepend Timestamp are toggle items that change
between yes or no when selected.
• In the Main Menu, choose Instrument Controls > Communication
Settings > Streaming Data Config.
Streaming Data Interval The Streaming Data Interval screen is used to adjust the streaming data
interval. The following interval times are available: 1, 2, 5, 10, 20, 30, 60,
90, 120, 180, 240, and 300 seconds.
• In the Main Menu, choose Instrument Controls > Communication
Settings > Streaming Data Config > Interval.
• Use and to scroll through a list of choices.
STREAMING DATA CONFIG:
INTERVAL 10 SEC
ADD LABELS NO
PREPEND TIMESTAMP YES
>ITEM 1 NO2
ITEM 2 INTT
ITEM 3 PRES
ITEM 4 NONE
ª
RANGE AVG DIAGS ALARM
CHOOSE STREAM DATA:
>CONCENTRATIONS
OTHER MEASUREMENTS
ANALOG INPUTS
RANGE AVG DIAGS ALARM
