MEC 320 GENSET CONTROLLER
PM079 Rev 0 07/06/08 72 Thomson Technology
Protection
1010 Reverse power
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
1011
Reverse power Set point -50.0% 0.0% - -5.0%
1012
Reverse power Timer 0.1 s 100.0 s - 10.0 s
1013
Reverse power Relay output A R0 (none) - R0 (none)
1014
Reverse power Relay output B R0 (none)
Option
dependent
- R0 (none)
1015
Reverse power Enable OFF ON RUN ON
1016
Reverse power Fail class Alarm (1) Trip MB (6) - Trip GB (3)
1020 Overcurrent 1
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
1021
Overcurrent 1 Set point 50.0% 200.0% - 115.0%
1022
Overcurrent 1 Timer 0.1 s 100.0 s - 10.0 s
1023
Overcurrent 1 Relay output A R0 (none) - R0 (none)
1024
Overcurrent 1 Relay output B R0 (none)
Option
dependent
- R0 (none)
1025
Overcurrent 1 Enable OFF ON RUN ON
1026
Overcurrent 1 Fail class Alarm (1) Trip MB (6)
- Warning (2)
1030 Overcurrent 2
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
1031
Overcurrent 2 Set point 50.0% 200.0% - 120.0%
1032
Overcurrent 2 Timer 0.1 s 100.0 s - 5.0 s
1033
Overcurrent 2 Relay output A R0 (none) - R0 (none)
1034
Overcurrent 2 Relay output B R0 (none)
Option
dependent
- R0 (none)
1035
Overcurrent 2 Enable OFF ON RUN ON
1116
Overcurrent 2 Fail class Alarm (1) Trip MB (6)
- Trip GB (3)
