MEC 320 GENSET CONTROLLER
PM079 Rev 0 07/06/08 91 Thomson Technology
Mains setup
6500 Mains power
No. Setting Min. setting Max. setting Factory
setting
6501 Mains power Day -20000 kW 20000 kW 750 kW
6502 Mains power Night -20000 kW 20000 kW 1000 kW
6503 Mains power Transducer max 0 kW 20000 kW 1500 kW
6504 Mains power Transducer min -20000 kW 0 kW -1500 kW
6510 Daytime period
The period outside the daytime period is defined as the nighttime period.
No. Setting Min. setting Max. setting Factory
setting
6511 Daytime period Start hour 0 h 23 h 8 h
6512 Daytime period Start minute 0 min 59 min 0 min
6513 Daytime period Stop hour 0 h 23 h 16 h
6514 Daytime period Stop minute 0 min 59 min 0 min
6520 Start gen-set
The set point refers to the mains power set points in
6500 Mains power
.
No. Setting Min. setting Max. setting Factory
setting
6521 Start generator Set point 5% 100% 80%
6522 Start generator Timer 0.0 s 990.0 s 10.0 s
6523 Start generator Minimum load 0% 100% 5%
6530 Stop gen-set
The set point refers to the mains power set points in
6500 Mains power
.
No. Setting Min. setting Max. setting Factory
setting
6531 Stop generator Set point 0% 80% 60%
6532 Stop generator Timer 0.0 s 990.0 s 30.0 s
6540 Test running
No. Setting Min. setting Max. setting Factory
setting
6541 Test Set point 1% 100% 80%
6542 Test Timer 0.5 min 999.0 min 5.0 min
6543 Test Return Semi-auto Auto Auto
6550 Fixed power set point
No. Setting Min. setting Max. setting Factory
setting
6551 Fixed power set point P set point 0% 100% 100%
Transducer max. equals 20mA, and Transducer min. equals 4mA. Both settings
must be adjusted.
