THOMSON MEC 320 - GENSET CONTROLLER User Manual

MEC 320 GENSET CONTROLLER
PM079 Rev 0 07/06/08 78 Thomson Technology
Input/output
This menu consists of parameters for configuration of the inputs and outputs.
Binary input setup
3260 Dig. input no. 110
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3261 Dig. input no. 110 Timer 0.0 s 100.0 s - 10.0 s
3262 Dig. input no. 110 Relay output A R0 (none) - R0 (none)
3263 Dig. input no. 110 Relay output B R0 (none)
Option
dependent
- R0 (none)
3264 Dig. input no. 110 Enable OFF ON RUN OFF
3265 Dig. input no. 110 Fail class Alarm (1) Trip MB (6) - Warning (2)
3266 Dig. input no. 110 Type N/O N/C - N/O
3270 Dig. input no. 111
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3271 Dig. input no. 111 Timer 0.0 s 100.0 s - 10.0 s
3272 Dig. input no. 111 Relay output A R0 (none) - R0 (none)
3273 Dig. input no. 111 Relay output B R0 (none)
Option
dependent
- R0 (none)
3274 Dig. input no. 111 Enable OFF ON RUN OFF
3275 Dig. input no. 111 Fail class Alarm (1) Trip MB (6) - Warning (2)
3276 Dig. input no. 111 Type N/O N/C - N/O
3280 Dig. input no. 112
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3281 Dig. input no. 112 Timer 0.0 s 100.0 s - 10.0 s
3282 Dig. input no. 112 Relay output A R0 (none) - R0 (none)
3283 Dig. input no. 112 Relay output B R0 (none)
Option
dependent
- R0 (none)
3284 Dig. input no. 112 Enable OFF ON RUN OFF
3285 Dig. input no. 112 Fail class Alarm (1) Trip MB (6) - Warning (2)
3286 Dig. input no. 112 Type N/O N/C - N/O
3290 Dig. input no. 113
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3291 Dig. input no. 113 Timer 0.0 s 100.0 s - 10.0 s
3292 Dig. input no. 113 Relay output A R0 (none) - R0 (none)
3293 Dig. input no. 113 Relay output B R0 (none)
Option
dependent
- R0 (none)
3294 Dig. input no. 113 Enable OFF ON RUN OFF
3295 Dig. input no. 113 Fail class Alarm (1) Trip MB (6) - Warning (2)
3296 Dig. input no. 113 Type N/O N/C - N/O
3300 Access lock (binary input 114)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3301 Access lock Timer 0.0 s 180.0 s - 10.0 s
3302 Access lock Relay output A R0 (none) - R0 (none)
3303 Access lock Relay output B R0 (none)
Option
dependent
- R0 (none)
3304 Access lock Enable OFF ON RUN OFF
3305 Access lock Fail class Alarm (1) Trip MB (6) - Warning (2)
3306 Access lock Type N/O N/C - N/O
