THOMSON MEC 320 - GENSET CONTROLLER User Manual

MEC 320 GENSET CONTROLLER
PM079 Rev 0 07/06/08 74 Thomson Technology
2070 GB general failure
- Synchronization time Adjustable time delay channel 2071
- Breaker ON/OFF feedback fail. 1 second fixed time delay
- Phase sequence error 1 second fixed time delay
No. Setting Min. setting Max. setting Factory
setting
2071 GB general fail. Delay 30.0 s 300.0 s 60.0 s
2072 GB general fail. Relay output A R0 (none) R0 (none)
2073 GB general fail. Relay output B R0 (none)
Option
dependent
R0 (none)
The general failure alarms cannot be disabled.
2080 MB general failure
- Synchronization time Adjustable time delay channel 2081
- Breaker ON/OFF feedback fail. 1 second fixed time delay
- Phase sequence error 1 second fixed time delay
No. Setting Min. setting Max. setting Factory
setting
2081 MB general fail. Delay 30.0 s 300.0 s 60.0 s
2082 MB general fail. Relay output A R0 (none) R0 (none)
2083 MB general fail. Relay output B R0 (none)
Option
dependent
R0 (none)
The general failure alarms cannot be disabled.
2090 Breaker failure alarms
The fail class of the breaker open and close failure alarms can be adjusted in this menu.
No. Setting Min. setting Max. setting Factory
setting
2091 MB open failure Fail class 1 6 2 (warning)
2092 MB close failure Fail class 1 6 2 (warning)
2093 GB open failure Fail class 1 6 2 (warning)
2094 GB close failure Fail class 1 6 2 (warning)
See page 53 regarding fail class selection.
2100 Separate Synchronization relay
No. Setting Min. setting Max. setting Factory
setting
2101 Generator breaker Relay output A R0 (none) R0 (none)
2102 Mains breaker Relay output B R0 (none)
Option
dependent
R0 (none)
2110 Close before excitation
No. Setting Min. setting Max. setting Factory
setting
2111 Close bf. excit. Set point 0 RPM 4000 RPM 400 RPM
2112 Close bf. excit. Timer 0.0 s 999.0 s 5.0 s
2113 Close bf. excit. Relay output A R0 (none) R0 (none)
2114 Close bf. excit. Relay output B R0 (none)
Option
dependent
R0 (none)
2115 Close bf. excit. Enable OFF ON OFF
