4130 Fuel level 1
(4…20mA input 102.1)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4131 4…20mA input 102.1 Set point 0% 120% - 10%
4132 4…20mA input 102.1 Timer 0.0 s 600.0 s - 120.0 s
4133 4…20mA input 102.1 Relay output A R0 (none) - R0 (none)
4134 4…20mA input 102.1 Relay output B R0 (none)
Option
dependent
- R0 (none)
4135 4…20mA input 102.1 Enable OFF ON RUN OFF
4136 4…20mA input 102.1 Fail class Alarm (1) Trip MB (6) - Warning (2)
4140 Fuel level 2
(4…20mA input 102.2)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4141 4…20mA input 102.2 Set point 0% 120% - 10%
4142 4…20mA input 102.2 Timer 0.0 s 600.0 s - 120.0 s
4143 4…20mA input 102.2 Relay output A R0 (none) - R0 (none)
4144 4…20mA input 102.2 Relay output B R0 (none)
Option
dependent
- R0 (none)
4145 4…20mA input 102.2 Enable OFF ON RUN OFF
4146 4…20mA input 102.2 Fail class Alarm (1) Trip MB (6) - Warning (2)
4170 VDO 104.1
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4171 VDO 104.1 Set point 0.0 bar 10.0 bar - 4.0 bar
4172 VDO 104.1 Timer 0.0 s 100.0 s - 5.0 s
4173 VDO 104.1 Relay output A R0 (none) - R0 (none)
4174 VDO 104.1 Relay output B R0 (none)
Option
dependent
- R0 (none)
4175 VDO 104.1 Enable OFF ON RUN OFF
4176 VDO 104.1 Fail class Alarm (1) Trip MB (6) - Warning (2)
4180 VDO 104.2
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4181 VDO 104.2 Set point 0.0 bar 10.0 bar - 5.0 bar
4182 VDO 104.2 Timer 0.0 s 100.0 s - 5.0 s
4183 VDO 104.2 Relay output A R0 (none) - R0 (none)
4184 VDO 104.2 Relay output B R0 (none)
Option
dependent
- R0 (none)
4185 VDO 104.2 Enable OFF ON RUN OFF
4186 VDO 104.2 Fail class Alarm (1) Trip MB (6) - Trip/stop (4)
4190 VDO 105.1
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4191 VDO 105.1 Set point 40 deg. 150 deg. - 100 deg.
4192 VDO 105.1 Timer 0.0 s 100.0 s - 5.0 s
4193 VDO 105.1 Relay output A R0 (none) - R0 (none)
4194 VDO 105.1 Relay output B R0 (none)
Option
dependent
- R0 (none)
4195 VDO 105.1 Enable OFF ON RUN OFF
4196 VDO 105.1 Fail class Alarm (1) Trip MB (6) - Warning (2)
