THOMSON MEC 320 - GENSET CONTROLLER User Manual

MEC 320 GENSET CONTROLLER
PM079 Rev 0 07/06/08 85 Thomson Technology
Output setup
5090 Relay 9
The relay 9 is available, if options D1 are not selected and analogue governor outputs are not
used.
No. Setting First/min.
setting
Second/max.
setting
Third
setting
Factory
setting
5091 Relay 9 Function Alarm Limit Horn Alarm
5092 Relay 9 Off delay 0.0 s 999.9 s - 5.0 s
5100 Relay 10
The relay 10 is available, if options D1 are not selected and analogue governor outputs are not
used.
No. Setting First/min.
setting
Second/max.
setting
Third
setting
Factory
setting
5101 Relay 10 Function Alarm Limit Horn Alarm
5102 Relay 10 Off delay 0.0 s 999.9 s - 5.0 s
5110 Relay 11
No. Setting First/min.
setting
Second/max.
setting
Third
setting
Factory
setting
5111 Relay 11 Function Alarm Limit Horn Alarm
5112 Relay 11 Off delay 0.0 s 999.9 s - 5.0 s
5120 Relay 12
The relay 12 is available, if ‘Continues’ is selected in menu 5491.
No. Setting First/min.
setting
Second/max.
setting
Third
setting
Factory
setting
5121 Relay 12 Function Alarm Limit Horn Alarm
5122 Relay 12 Off delay 0.0 s 999.9 s - 5.0 s
5130 Relay 13
The relay 13 is available, if ‘Continues’ is selected in menu 5492.
No. Setting First/min.
setting
Second/max.
setting
Third
setting
Factory
setting
5131 Relay 13 Function Alarm Limit Horn Alarm
5132 Relay 13 Off delay 0.0 s 999.9 s - 5.0 s
5490 Transistor setup
The transistor outputs on terminals 20 and 21 can be configured as constant or pulse signals. If
‘Continues’ is selected, the relays 12 and 13 will be available.
No. Setting First/min.
setting
Second/max.
setting
Factory setting
5491 Transistor 20 T20 Continues kWh kWh
5492 Transistor 21 T21 Continues kVar kVarh
If the transistor outputs are set to ‘Continues’, external relays are needed due to
the limited current output of the transistors. Max 10mA.
