THOMSON MEC 320 - GENSET CONTROLLER User Manual

MEC 320 GENSET CONTROLLER
PM079 Rev 0 07/06/08 59 Thomson Technology
The 8 curve settings for the configurable VDO inputs cannot be changed in the display, but
only
in the PC utility software. The alarm settings can be changed both in the display and in the PC
utility software. In the PC utility software the configurable inputs are adjusted in this dialog box:
Adjust the resistance of the VDO sensor at the specific measuring value. In the example above
the adjustment is 10 at 0.0 bar.
Language selection
The unit has the possibility to display different languages. English is the default language, and it
cannot be changed. In addition to the master language 11 different languages can be
configured. This is done via the PC utility software.
The languages are selected in the system setup
(6130 Language)
The language can be changed when connected to the PC utility software. It is not possible to
make language configuration from the display, but the already configured languages can be
selected.
Buttons used in the PC utility software
Retrieve languages from the device:
Activating this button will retrieve the configured languages from the device.
Send languages to the device:
Activating this button will send the content of the 11 language frames to the device.
Synchronize a language file with the device:
Activating this button will synchronize a language file from a previous version of the
software with a newer version. New functions that are not translated will be marked.
Copy master language to other languages:
Activating this button will send the master language to the 11 language frames
(except for the already configured texts).

THOMSON MEC 320 - GENSET CONTROLLER Specifications

General

Brand	THOMSON
Model	MEC 320 - GENSET CONTROLLER
Category	Controller
Language	English
