THOMSON MEC 320 - GENSET CONTROLLER User Manual

MEC 320 GENSET CONTROLLER
PM079 Rev 0 07/06/08 80 Thomson Technology
Analogue input setup
4090 4…20mA input 98.1
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4091 4…20mA input 98.1 Set point 4mA 20mA - 10mA
4092 4…20mA input 98.1 Timer 0.0 s 600.0 s - 120.0 s
4093 4…20mA input 98.1 Relay output A R0 (none) - R0 (none)
4094 4…20mA input 98.1 Relay output B R0 (none)
Option
dependent
- R0 (none)
4095 4…20mA input 98.1 Enable OFF ON RUN OFF
4096 4…20mA input 98.1 Fail class Alarm (1) Trip MB (6) - Warning (2)
4100 4…20mA input 98.2
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4101 4…20mA input 98.2 Set point 4mA 20mA - 10mA
4102 4…20mA input 98.2 Timer 0.0 s 600.0 s - 120.0 s
4103 4…20mA input 98.2 Relay output A R0 (none) - R0 (none)
4104 4…20mA input 98.2 Relay output B R0 (none)
Option
dependent
- R0 (none)
4105 4…20mA input 98.2 Enable OFF ON RUN OFF
4106 4…20mA input 98.2 Fail class Alarm (1) Trip MB (6) - Warning (2)
4110 Oil pressure 1
(4…20mA input 100.1)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4111 Oil pressure 1 Set point 0 bar 50 bar - 10 bar
4112 Oil pressure 1 Timer 0.0 s 180.0 s - 5.0 s
4113 Oil pressure 1 Relay output A R0 (none) - R0 (none)
4114 Oil pressure 1 Relay output B R0 (none)
Option
dependent
- R0 (none)
4115 Oil pressure 1 Enable OFF ON RUN OFF
4116 Oil pressure 1 Fail class Alarm (1) Trip MB (6) - Warning (2)
4120 Oil pressure 2
(4…20mA input 100.2)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4121 Oil pressure 2 Set point 0 bar 50 bar - 10 bar
4122 Oil pressure 2 Timer 0.0 s 180.0 s - 5.0 s
4123 Oil pressure 2 Relay output A R0 (none) - R0 (none)
4124 Oil pressure 2 Relay output B R0 (none)
Option
dependent
- R0 (none)
4125 Oil pressure 2 Enable OFF ON RUN OFF
4126 Oil pressure 2 Fail class Alarm (1) Trip MB (6) - Warning (2)
The input is not configurable in the peak shaving mode, load takeover mode and
mains power export, because it is used as a mains power input.
The input is not config
urable in the peak shaving mode, load takeover mode and
mains power export, because it is used as a mains power input.
