MEC 320 GENSET CONTROLLER
PM079 Rev 0 07/06/08 8 Thomson Technology
4. Functional descriptions
This chapter includes functional descriptions of standard functions as well as illustrations of the
relevant application types. Flowcharts and single-line diagrams will be used in order to simplify
the information.
Standard functions
In the following paragraphs the standard functions are listed.
Operation modes
•
Automatic Mains Failure
•
Load take over
Engine control
•
Start/stop sequences
•
Fuel solenoid selection
•
Relay outputs for governor control
Protections (ANSI)
•
Overcurrent, 2 levels (51)
•
Reverse power (32)
•
4-20mA inputs
•
PT100 or VDO inputs
•
Digital inputs
Display
•
Prepared for remote mounting
•
Push-buttons for start and stop
•
Push-buttons for breaker operations
•
Status texts
M-logic
•
Simple logic configuration tool
•
Selectable input events
•
Selectable output commands
