Page #56 background imageLoading...
Page #56 background image
MEC 320 GENSET CONTROLLER
PM079 Rev 0 07/06/08 56 Thomson Technology
VDO inputs
There are three VDO inputs in the unit. The inputs have different functions, as the hardware
design allows for several VDO types.
VDO input 104: Oil pressure
VDO input 105: Cooling water temperature
VDO input 106: Fuel level sensor
VDO input 104
This VDO input is used for measuring the lubricating oil pressure.
VDO sensor type
Pressure Type 1 Type 2 Type configurable
Bar
0 10.0 10.0 Point 1
0.5 27.2
1.0 44.9 31.3
1.5 62.9
2.0 81.0 51.5
2.5 99.2 Point 2
3.0 117.1 71.0
3.5 134.7
4.0 151.9 89.6
4.5 168.3
5.0 184.0 107.3 Point 3
6.0 124.3 Point 4
7.0 140.4 Point 5
8.0 155.7 Point 6
9.0 170.2 Point 7
10.0 184.0 Point 8
Level switch type
VDO sensor type
Type level switch
Resistance Function
>200 Normal situation, no alarm
<200 Alarm situation
The configurable type is configurable with 8 points.
If the VDO input is used as a level switch, then be aware that no voltage must be
connected to the input. If any voltage is applied to the VDO inpu
ts, then it will be
damaged. Refer to the Application Notes for further wiring information.
