THOMSON MEC 320 - GENSET CONTROLLER User Manual

MEC 320 GENSET CONTROLLER
PM079 Rev 0 07/06/08 57 Thomson Technology
VDO input 105
This VDO input is used for measuring the cooling water temperature.
VDO sensor
type
Temperature Type 1 Type 2 Type 3 Type 4
°C    
40 291.5 480.7 69.3 Point 1
50 197.3 323.6 Point 2
60 134.0 222.5 36.0 Point 3
70 97.1 157.1 Point 4
80 70.1 113.2 19.8 Point 5
90 51.2 83.2 Point 6
100 38.5 62.4 11.7 Point 7
110 29.1 47.6 Point 8
120 22.4 36.8 7.4
130 28.9
140 22.8
150 18.2
Level switch type
VDO sensor type
Type 3
Resistance Function
<1.7k Normal situation, no alarm
>1.7k Alarm situation
VDO input 106
This VDO input is used for the fuel level sensor.
VDO sensor type
Type 1
Value Resistance
0% 78.8
100% 1.6
VDO sensor type
Type 2
Value Resistance
0% 3
100% 180
The configurable type is configurable with 8 points.
If the VDO input is used as a level switch, then be aware that no voltage must be
connected to the input. If any voltage is applied t
o the VDO inputs, then it will be
damaged. Refer to the Application Notes for further wiring information.
If the VDO input is used as a level switch, then be aware that no voltage must be
connected to the input. If any voltag
e is applied to the VDO inputs, then it will be
damaged. Refer to the Application Notes for further wiring information.
