MEC 320 GENSET CONTROLLER
PM079 Rev 0 07/06/08 79 Thomson Technology
3310 Running feedback (binary input 115)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3311 Run. feedback Timer 0.0 s 180.0 s - 10.0 s
3312 Run. feedback Relay output A R0 (none) - R0 (none)
3313 Run. feedback Relay output B R0 (none)
Option
dependent
- R0 (none)
3314 Run. feedback Enable OFF ON RUN OFF
3315 Run. feedback Fail class Alarm (1) Trip MB (6) - Warning (2)
3316 Run. feedback Type N/O N/C - N/O
3320 Ext. engine failure (binary input 116)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3321 Engine failure Timer 0.0 s 180.0 s - 10.0 s
3322 Engine failure Relay output A R0 (none) - R0 (none)
3323 Engine failure Relay output B R0 (none)
Option
dependent
- R0 (none)
3324 Engine failure Enable OFF ON RUN OFF
3325 Engine failure Fail class Alarm (1) Trip MB (6) - Shutdown (5)
3326 Engine failure Type N/O N/C - N/O
3330 Ext. emergency stop (binary input 117)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3331 Emergency STOP Timer 0.0 s 60.0 s - 0.0 s
3332 Emergency STOP Relay output A R0 (none) - R0 (none)
3333 Emergency STOP Relay output B R0 (none)
Option
dependent
- R0 (none)
3334 Emergency STOP Enable OFF ON RUN OFF
3335 Emergency STOP Fail class Alarm (1) Trip MB (6) - Shutdown (5)
3336 Emergency STOP Type N/O N/C - N/O
3340 Dig. input no. 118
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3341 Dig. input no. 118 Timer 0.0 s 100.0 s - 10.0 s
3342 Dig. input no. 118 Relay output A R0 (none) - R0 (none)
3343 Dig. input no. 118 Relay output B R0 (none)
Option
dependent
- R0 (none)
3344 Dig. input no. 118 Enable OFF ON RUN OFF
3345 Dig. input no. 118 Fail class Alarm (1) Trip MB (6) - Warning (2)
3346 Dig. input no. 118 Type N/O N/C - N/O
