MEC 320 GENSET CONTROLLER
PM079 Rev 0 07/06/08 86 Thomson Technology
System
The menu includes parameters for the system setup.
General setup
6010 Nominal settings 1
No. Setting Min. setting Max. setting Factory
setting
6011 Nominal settings 1 Frequency 48.0Hz 62.0Hz 50.0Hz
6012 Nominal settings 1 Generator power 10kW 20000kW 480kW
6013 Nominal settings 1 Generator current 0A 9000A 867A
6014 Nominal settings 1 Generator volt. 100V 25000V 400V
6020 Nominal settings 2
No. Setting Min. setting Max. setting Factory
setting
6021 Nominal settings 2 Frequency 48.0Hz 62.0Hz 60.0Hz
6022 Nominal settings 2 Generator power 10kW 20000kW 285kW
6023 Nominal settings 2 Generator current 0A 9000A 345A
6024 Nominal settings 2 Generator volt. 100V 25000V 480V
6025 Nominal settings 2 Set OFF 2 OFF
6030 Transformer gen.
No. Setting Min. setting Max. setting Factory
setting
6031 Transformer gen. Volt. prim. 100V 25000V 400V
6032 Transformer gen. Volt. sec. 100V 690V 400V
6033 Transformer gen. Current prim. 5A 9000A 1000A
6034 Transformer gen. Current sec. 1A 5A 5A
6040 Transformer bus.
No. Setting Min. setting Max. setting Factory
setting
6041 Transformer bus. Volt. prim. 100V 25000V 400V
6042 Transformer bus. Volt. sec. 100V 690V 400V
6050 Engine type
No. Setting First setting Second
setting
Factory
setting
6051 Engine type Engine type Diesel
engine
None Diesel
engine
If no voltage transformer is present, the primary and secondary side values are
set to generator nominal value.
It is only possible to select diesel engine.
If no voltage transform
er is present, the primary and secondary side values are
set to generator nominal value.
