3.1 Parts List – Accessories
PM100 / page 7
3.1 Parts List – Accessories
The power meter system consists of the following items:
• PM100 Universal power meter console with
o PMBAT Rechargeable and replaceable
3.6V 1500mAh NiMH battery pack
• CABSER Serial Interface cable; 9p Sub-D female on both ends
• Operation manual
• CD-ROM with all software included
• PMPS9 Power supply (9V, 1.1A), 85 .. 264V line voltage,
included line adaptors for US, EU, UK.
Depending on the order code the power meter system comes with one of the sensors
given below:
PM120: S120B – Silicon Sensor Power Head; 50nW – 50mW; 400 – 1100nm
PM121: S121B – Silicon Sensor Power Head; 500nW – 500mW; 400 – 1100nm
PM122: S122B – Germanium Sensor Power Head; 35nW – 35mW;
700 – 1800nm
PM130: S130A – Slim, dual range Silicon Sensor Power Head;
5nW – 500mW; 400 – 1100nm
PM132: S130A – Slim, dual range Germanium Sensor Power Head;
5nW – 500mW; 400 – 1100nm
PM140: S140A – Integrating Sphere Silicon Sensor Power Head;
1µW – 1W; 400 – 1100nm
PM144: S144A – Integrating Sphere InGaAs Sensor Power Head;
1µW – 1W; 800 – 1700nm
PM210: S210A – Thermal Power Head; 20mW – 3W; 250nm – 10.6µm
PM212: S212A – Thermal Power Head; 20mW – 10W; 250nm – 10.6µm
PM213: S213A – Thermal Power Head; 100mW – 30W; 250nm – 10.6µm
