3.3 Physical Overview
PM100
/ page 16
3.3 Physical
Overview
Figure 2
PM100 Operating Elements
Figure 3
Top Plate Operating Elements
On/Off
Wavelength correction
(Photodiode heads)
Range Menu
Enter
Zero / Relative
Measurement
Display Selection
Backlight
Navigation
DB9 Sensor Jack
SMA Analog Output Jack
