23
Smart AC1/TD
w w w . t i m e t e c c l o u d . c o m
Wiegand Format
Wiegand34a
Wiegand36
Wiegand36a
Wiegand37
Wiegand37a
Wiegand50
Definitions
ESSSSSSSSCCCCCCCCCCCCCCCCCCCCCCCCO
Consists of 34 bits of binary code. The 1st bit is the even parity bit
of the 2nd to 17th bits, while the 34th bit is the odd parity bit of
the 18th to 33rd bits. The 2nd to 9th bits are the site codes, while
the 10th to 25th bits are the card numbers.
OFFFFFFFFFFFFFFFFCCCCCCCCCCCCCCCCMME
Consists of 36 bits of binary code. The 1st bit is the odd parity bit
of the 2nd to 18th bits, while the 36th bit is the even parity bit of
the 19th to 35th bits. The 2nd to 17th bits are the device codes.
The 18th to 33rd bits are the card numbers, and the 34th to 35th
bits are the manufacturer codes.
EFFFFFFFFFFFFFFFFFFCCCCCCCCCCCCCCCCO
Consists of 36 bits of binary code. The 1st bit is the even parity bit
of the 2nd to 18th bits, while the 36th bit is the odd parity bit of
the 19th to 35th bits. The 2nd to 19th bits are the device codes,
and the 20th to 35th bits are the card numbers.
OMMMMSSSSSSSSSSSSCCCCCCCCCCCCCCCCCCCE
Consists of 37 bits of binary code. The 1st bit is the odd parity bit
of the 2nd to 18th bits, while the 37th bit is the even parity bit of
the 19th to 36th bits. The 2nd to 4th bits are the manufacturer
codes. The 5th to 16th bits are the site codes, and the 21st to 36th
bits are the card numbers.
EMMMFFFFFFFFFFSSSSSSCCCCCCCCCCCCCCCCO
Consists of 37 bits of binary code. The 1st bit is the even parity
bit of the 2nd to 18th bits, while the 37th bit is the odd parity bit
of the 19th to 36th bits. The 2nd to 4th bits are the manufacturer
codes. The 5th to 14th bits are the device codes, and15th to
20th bits are the site codes, and the 21st to 36th bits are the card
numbers.
ESSSSSSSSSSSSSSSSCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCO
Consists of 50 bits of binary code. The 1st bit is the even parity bit
of the 2nd to 25th bits, while the 50th bit is the odd parity bit of
“C “denotes the card number; “E” denotes the even parity bit; “O” denotes the odd parity bit;
“F“ denotes the facility code; “M” denotes the manufacturer code; “P” denotes the parity bit;
and “S” denotes the site code.
