24
Smart AC1/TD
w w w . t i m e t e c c l o u d . c o m
Wiegand output
Items
SRB
Wiegand Format
Wiegand output bits
Failed ID
Site Code
Pulse Width(us)
Pulse Interval(us)
ID Type
Descriptions
When SRB is enabled, the lock is controlled by the SRB to prevent
the lock from being opened due to device removal.
Values range from 26 bits, 34 bits, 36 bits, 37 bits, and 50 bits.
After choosing the Wiegand format, you can select one of the
corresponding output digits in the Wiegand format
If the verification is failed, the system will send the failed ID to
the device and replace the card number or personnel ID with the
new ones.
It is similar to the device ID. The difference is that a site code can
be set manually, and is repeatable in a different device. The valid
value ranges from 0 to 256 by default.
The time width represents the changes of the quantity of electric
charge with high-frequency capacitance regularly within a speci-
fied time.
The time interval between pulses.
Select between User ID and badge number.
