Toa RM-200M - System Configuration

6
System: In-building Mass Notification Systems for voice evacuation.
•
Autonomous Control Unit (ACU): VM-3240VA
•
Number of ACUs: Single interface on the VM-3240VA.
•
The wiring should be connected as follows:
VM LINK between VM-3240VA and VM-3240E
DS LINK between VM-3240VA/E and VX-2000DS
•
Class B wiring: SP OUTPUT, CTRL IN, EMERGENCY CONTROL IN1, IN2, STATUS OUT
•
All circuits expect SP OUTPUT are Power Limited.
•
At least one set of VX-2000DS and batteries should be used to provide secondary power supply
for emergency purposes and be installed in the same rack as the VM-3240VA and/or VM-3240E.
•
The RM-200M cannot be used for Emergency purposes.
•
SP OUTPUTs are supervised and the RM1/2 LINK and DC22 V OUT are not supervised.
•
The audio inputs of input 1 – 4, BGM, and RM-200M, and the audio sources of the built-in General EV
1 – 6 cannot be used for Emergency purposes.
•
The VM-3240VA should be installed in the following locations:
(1) Within a key-locked cabinet or rack with physical security level 1 or higher
(2) In a controlled access room with a minimum access control security level 1.
Front-mounted controls should only be changed by Authorized Personnel.
•
The system is provided with a Communication Security Level 0, which indicates no Security Level
employed.
•
RM-200M should be installed in the same room or within 20 ft (6.1 m) of the equipment rack unless
CAT5 UL listed transient suppression devices (Tripp Lite DSUT1CSU or equal) is installed on both
ends of the RM LINK.
•
The following wiring connections are intended to be made in the same room within 20 ft (6.1 m) of
each other and are enclosed within conduit or equivalently protected against mechanical damage.
EMERGENCY CONTROL IN and CTRL IN between VM-3240VA or VM-3240E and Fire
Alarm Control Panel or Notification Appliance Circuits.
VM LINK between VM-3240VA and VM-3240E.
STATUS OUT between VM-3240VA or VM-3240E and Fire Alarm Control Panel or Notification
Appliance Circuits
CTRL IN between VM-3240VA or VM-3240E and audio sources.
•
Password must be set (refer to p. 48).
•
BGM Volume must be set to lower than 70%.
•
The FACP and TOA MNS units need to be installed adjacent to each other.
•
The system is not to be used in buildings providing Suppression Service (Systems using Halon, etc.).
Sprinkled systems are allowed.
Installation for Listed/Certified UL2572 and CAN/ULC-S576 Mass Notification Systems
