Toa RM-200M - Sample System 1

8
• Sample System 1
This example is ideal for installation in facilities and churches does not need the FACP.
•
A 200 W integrated emergency/general broadcast system with 6 outputs.
•
Emergency broadcasts can be made even during power failures. However, general broadcasts are not
possible.
Lead-acid Battery
VX-2000DS
RM-200M
Notification Appliance Circuit
VM-3240VA
DC POWER
RM LINK 1
DC POWER
DS LINK
STATUS OUT EMERGENCY CONTROL IN
3. SYSTEM CONFIGURATION
