Toa RM-200M - Sample System 2

9
Lead-acid Battery
VX-2000DS
VM-3240E
VM-3240E
RM-200M
RM-200M
Fire Alarm Control Panel
Notification Appliance Circuit
VM-3240VA
DC POWER
DC POWER
VM LINK
RM LINK 1
RM LINK 2
DC POWER
DS LINK
VM LINK
STATUS OUT EMERGENCY
CONTROL IN
STATUS OUT EMERGENCY CONTROL IN
• Sample System 2
This example is ideal for installation in large stores applied to the FACP with FACP-Strobe for FACP use only
and separate MNS-Strobe for MNS use only.
•
A 600 W integrated emergency/general broadcast system with 18 outputs.
•
Emergency broadcasts can be made even during power failures. However, general broadcasts are not
possible.
