Toa RM-200M - FACP and NAC Extender connection B

92
[FACP and NAC Extender connection B]
MNS System has lower Priority.
VM-3240VA rear
VM-3240E rear
EMERGENCY STATUS OUT
CTRL IN 1
10 kΩ
COM 1
1
2
3
4
5
6
7
8
FACP
MNS ACTIVE INPUT
FACP FAULT OUTPUT
MNS FAULT INPUT
FACP ACTIVE OUTPUT
FAULT STATUS OUT
EMERGENCY STATUS OUT
CTRL IN 2
10 kΩ
COM 2
1
2
3
4
5
6
7
8
NAC EXTENDER
NAC FAULT OUTPUT
MNS-NAC
ACTIVE INPUT
CTRL IN 4
COM 4
4.7 kΩ
4.7 kΩ
