Tomey AL-100 User Manual

3-19
[ACD] and [LENS] are not displayed with Aphakic, and
[LENS] is not displayed with Pseudophakic.
Posterier lens waveform might not be recognized, due to mul-
tiple echo with Dense Cataract mode.
Measured data is displayed.
Measured data may not be displayed.
Measured data is not displayed.
e-2) Setting of the gain (ultrasound emitter power)
Set the gain level based on the waveform amplitude. There
are 8 levels. The higher you set the gain, the larger the am-
plitude will be.
(Figure 1)
1) Touch (1) keys to adjust the gain with the window
(Fig. 1).
2) New value is displayed on main window.
