3-73 ■
3.9 System setup
Touch the “System Setup” button (1) on the Setup screen (Fig. 1) in each mode to
open the System Setup screen (Fig. 2).
1) The system setup consists of 4 major categories.
● General …Time, version information, etc.
● Measurement …Time, version information, etc.
● Application … Calculation, analysis, and correction
● Connection & Print … Connection and printing
Touch the menu tab (2) to open the corresponding setup screen. The setup
screen has a tree configuration. The displayed location is shown in the
address bar (3) and you can jump to the specified screen by touching the
displayed characters.
2) Touching the “Exit” button (4) will reflect the changes made and open the
measurement screen.
(1)
(3)
(4)
(2)
(Fig. 1)
)
(Fig. 2)
)
