2.4.4 Pachymetry screen
(1) Displays the actual measurements of the loaded measurement points. The latest loaded data
are displayed during a measurement process.
(2) Corneal thickness data display
(3) Measurement data display
(4) "Delete/Restore" button
(5) “Caliper” button
(6) “Meas. Point” button
(7) “Change Meas. Point” button
(8) Measurement waveform display field
(9) Measurement conditions display field
(10) "IOP" button
(11) “Differential” button
(12) “Calib.” button
Calibrates the sensitivity of pachymetry probes.
(3)
(7)
(4)
(5)
(9)
(1)
(2)
(6)
(12)
(11)
(8)
(10)
