3. Various Settings
49
Direct Input
The correction factor input screen is displayed.
The procedure for inputting the correction factor directly is as described below.
1 Press the [CHANGE] button.
The KX value can be input and, set the value.
Method for Setting a Value
☞
「3.1.3 Numerical Value Setting」
2 After KX has been input, press the [ENTER] button. Now KY can be input, so similarly set
the values for KY and KZ.
Calculation from Measurement
The reference data input screen for calculating the correction factor is displayed.
The procedure for calculating the correction factor from measurement is as described below.
1 Press the [CHANGE] button.
The value for x can be input so, set the value for reference data x.
Method for Setting a Value「3.1.3 Numerical Value Setting」
2 After the value for x has been input, press the [ENTER] button. Now, the value for y can
be input, so similarly input the values for y and L.
After the value for L has been input and the [ENTER] button has been pressed, the
following screen is displayed.
Ｋ０１ ＲＥＦ． ＩＮＰＵＴ
ｘ＝ ＊＊＊＊＊＊
ｙ＝ ＊＊＊＊＊＊
Ｌ＝ ＊＊＊＊＊＊＊＊＊
Ｋ０１ ＤＩＲＥＣＴ ＩＮＰＵＴ
ＫＸ＝ １．０００Ｅ+００
ＫＹ＝ １．０００Ｅ+００
ＫＺ＝ １．０００Ｅ+００
Ａｔｔｅｎｔｉｏｎ ！！
Ｐｌｅａｓｅ ｓｅｔ
ｔｈｅ Ｒｅｆ．ｓａｍｐｌｅ，ｔｈｅｎ
ｐｕｓｈ ＲＵＮ／ＨＯＬＤ ｋｅｙ．
