GR-3 Configuration
GR-3 Operator’s Manual
3-26
To configure, manage files, or maintain the receiver, connect the
receiver and a computer using one of the following methods, and start
PC-CDU:
• use a Bluetooth-enabled external device (computer)
• use an RS232 cable
• use a USB cable and a computer with the TPS USB driver
installed (available on the TPS website at
www.topconpositioning.com)
PC-CDU is Personal Computer-Control Display Unit software used
to manage the various functions of your receiver. The full range of
PC-CDU configuration and function is outside the scope of this
manual. For more information on any of the procedures in this section
or on PC-CDU, refer to the PC-CDU User’s Manual available on the
TPS website at www.topconpositioning.com.
PC-CDU configures the various parts of the receiver, saving the
settings in the receiver’s memory. These settings will be reflected
when you use the MINTER. The full range of PC-CDU configuration
and function is outside the scope of this manual.
Once you have established a connection between the receiver and the
computer, you can:
• configure the receiver and its components
• send commands to the receiver
• download files from the receiver’s memory
• load a new OAF and other configuration files to a receiver
The following Base and Rover configurations are recommended for
the most common applications; however, you can select configuration
parameters as needed for your particular jobsite.
1. Connect the receiver and computer as described in “Connecting
the Receiver and a Computer” on page 2-20.
Do not make other changes without consulting the
PC-CDU Reference Manual.
