Charging the Batteries
P/N 7010-0736
2-9
4. Carefully insert the holder, label side down, into the SIM card slot
located at the top of the battery pocket.
Figure 2-7. Install SIM Card
Once the receiver is turned on, the receiver board will detect the SIM
card, and it will be ready to use as needed.
Charging the Batteries
Before using the GR-3, fully charge the batteries for maximum
operating time (Figure 2-8 on page 2-10).
If the batteries are attached to the charging cradle or to the GR-3, an
approximately 6-hour charge cycle will fully charge the batteries; the
batteries charge simultaneously.
The batteries cannot be overcharged.
The batteries are shipped from the factory without
power. Fully charge the batteries before surveying.
