Configuring a Digital UHF Radio with a GSM Radio Modem
P/N 7010-0736
3-17
Configuring a Digital UHF
Radio with a GSM Radio
Modem
For the GR-3 Digital UHF, the integrated radio modem configured
with a Wavecom GSM Module provides TX/RX GSM
communications between a Base and Rover, or communications with
a GPS network using IP based connections. To configure a GSM
modem, have the following ready:
• PC running Windows 98 or newer
• Modem-TPS 2.2p2 or newer
• A Serial cable or Bluetooth connectivity with PC
1. Connect the computer and receiver using an RS-232 cable or
Bluetooth wireless technology. Turn on the receiver.
2. Open Modem-TPS and select the COM Port the receiver is
connected to (Figure 3-10). Click Connect.
Figure 3-10. Connect to Modem-TPS
To comply with RF exposure requirements,
maintain at least 25cm between the user and the
radio modem.
